Tip
ABL8
Nazivni tok (A)
40
Vhodna napetost (V)
24-28.9 V
Tip vhodne napetosti
DC
Izhodna napetost (V)
24-28.9 V
Tip izhodne napetosti
DC
Degree of protection (IP)
IP10
Type of electric connection
Screw connection
Voltage type of supply voltage
DC
Height (mm)
146
Width (mm)
44
Depth (mm)
140
Rail mounting possible
Yes
SIL according to IEC 61508
None
Performance level acc. EN ISO 13849-1
None
Suitable for safety functions
Yes
Modular version
Yes
Direct mounting possible
No
Stabilized
Yes
Short-circuit-proof
Yes
Power output (W)
145
Nominal value output current 1 (A)
40
Rated supply voltage at DC (V)
24 Volt
Nominal value output voltage 1 (V)
24
Max. output current 1 (A)
40
Output voltage stabilized
Yes
Wall mounting possible
No
1st secondary output voltage (V)
24 Volt
Secondary voltage adjustable
Yes
