Tip
ABL8
Nazivni tok (A)
6
Vhodna napetost (V)
24-28.8 V
Tip vhodne napetosti
DC
Izhodna napetost (V)
5 V
Tip izhodne napetosti
DC
Degree of protection (IP)
IP20
Type of electric connection
Screw connection
Voltage type of supply voltage
AC/DC
Height (mm)
143
Width (mm)
44
Depth (mm)
140
Rail mounting possible
Yes
SIL according to IEC 61508
None
Performance level acc. EN ISO 13849-1
None
Suitable for safety functions
Yes
Modular version
Yes
Direct mounting possible
No
Stabilized
Yes
Short-circuit-proof
Yes
Power output (W)
30
Nominal value output current 1 (A)
6
Rated supply voltage at DC (V)
24…28.8 Volt
Nominal value output voltage 1 (V)
5
Max. output current 1 (A)
6
Output voltage stabilized
Yes
Wall mounting possible
No
1st secondary output voltage (V)
5…6.5 Volt
Secondary voltage adjustable
Yes
