Degree of protection (IP)
IP20
Rated control supply voltage Us at AC 50HZ (V)
110 Volt
Rated control supply voltage Us at AC 60HZ (V)
110 Volt
Voltage type for actuating
AC/DC
Function
Single direction
Release class
Other
Rated operating voltage Ue (V)
230…600 Volt
With display
No
Rated operation current Ie at 40 °C Tu (A)
590
Internal bypass
Yes
Torque control
Yes
Rated power three-phase motor, inline, at 230 V (kW)
160
Rated power three-phase motor, inline, at 400 V (kW)
315
Integrated motor overload protection
Yes
Rated surrounding temperature without derating (°C)
40
