Tip
RM35
Širina (mm)
35
Nazivni tok (A)
5
Št. kontaktov
1 C/O
Izhod
relejski
Funkcija
kontrola s senzorjem
Kontrola
kontrola nivoja
Tip merilne napetosti
AC/DC
Max. preklopna napetost
250 V
Tip preklopne napetosti
AC/DC
Number of contacts as normally open contact
0
Number of contacts as change-over contact
1
Number of contacts as normally closed contact
0
Type of electric connection
Screw connection
Rated control supply voltage Us at AC 50HZ (V)
24…240 V
Rated control supply voltage Us at AC 60HZ (V)
24…240 V
Voltage type for actuating
AC/DC
Rated control supply voltage Us at DC (V)
24…240 V
Height (mm)
90
Width (mm)
35
Depth (mm)
72
With detachable clamps
No
Max. permitted off-delay time (s)
5
Min. adjustable off-delay time (s)
0.1
Response value sensitivity adjustable
Yes
Cascadable
No
Physical measurement principle
Float
Number of inputs for electrodes
3
Max. permitted operate delay time (s)
0.5
Min. adjustable operate delay time (s)
0.1
