Tip
RM35
Širina (mm)
35
Nazivni tok (A)
5
Št. kontaktov
1 C/O
Izhod
relejski
Funkcija
kontrola črpalke
Kontrola
kontrola črpalke
Tip merilne napetosti
AC
Max. preklopna napetost
250 V
Tip preklopne napetosti
AC/DC
Number of contacts as normally open contact
0
Number of contacts as change-over contact
1
Number of contacts as normally closed contact
0
Type of electric connection
Screw connection
Rated control supply voltage Us at AC 50HZ (V)
208…480 V
Rated control supply voltage Us at AC 60HZ (V)
208…480 V
Voltage type for actuating
AC/DC
Voltage type of supply voltage
AC
Height (mm)
90
Width (mm)
35
Depth (mm)
72
With detachable clamps
No
Three-phase over current possible
Yes
Contains function DC-voltage under current
No
Three-phase under current possible
Yes
Current measurement range (A)
1…10 Ampere
Single-phase over current possible
Yes
External current transformer
No
Single-phase under current possible
Yes
Single-phase hysteresis possible
Yes
Three-phase hysteresis possible
Yes
Function DC-current hysteresis
No
Contains function DC-voltage over current
No
Max. permitted off-delay time (s)
10
Min. adjustable off-delay time (s)
0.1
Max. permitted delay-on energization time (s)
60
Min. adjustable delay-on energization time (s)
1
