Max. nazivna moč pri 400 V AC (kW)
2.2
Degree of protection (IP)
IP40
Voltage type for actuating
DC
Rated control supply voltage Us at DC (V)
24 Volt
Suitable for emergency stop
No
Type of electrical connection of main circuit
Screw connection
Number of indicator lights
0
Supporting protocol for SERCOS
No
Rated conditional short-circuit current, type 1, 480 Y/277 V (A)
3
Rated conditional short-circuit current, type 2, 230 V (A)
3
Rated operation current Ie (A)
3
Rated conditional short-circuit current, type 1, 600 Y/347 V (A)
12
External reset possible
No
Ambient temperature, upper operating limit (°C)
70
With transformer
No
Rated operation current at AC-3, 400 V (A)
12
Type of electrical connection for auxiliary- and control current circuit
Screw connection
Rated conditional short-circuit current, type 2, 400 V (A)
12
Height (mm)
66
Supporting protocol for INTERBUS-Safety
No
Number of command positions
0
Width (mm)
45
Number of auxiliary contacts as normally closed contact
0
Supporting protocol for AS-Interface Safety at Work
No
Number of auxiliary contacts as normally open contact
0
Coordination class according to IEC 60947-4-3
Class 2
Depth (mm)
60
Supporting protocol for DeviceNet Safety
No
Supporting protocol for EtherNet/IP
No
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for SafetyBUS p
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for PROFINET IO
No
Supporting protocol for PROFIsafe
No
Supporting protocol for ASI
No
Kind of motor starter
Advanced control
Supporting protocol for PROFIBUS
No
Supporting protocol for TCP/IP
No
Supporting protocol for CAN
No
Supporting protocol for INTERBUS
No
Rail mounting possible
Yes
Supporting protocol for DeviceNet
No
Supporting protocol for MODBUS
No
Supporting protocol for Data-Highway
No
Supporting protocol for LON
No
With fuse
No
Supporting protocol for other bus systems
No
With short-circuit release
Yes
Supporting protocol for SUCONET
No
Overload release current setting (A)
3…12 Ampere
Temperature compensated overload protection
Yes
Release class
CLASS 10
