Max. nazivna moč pri 400 V AC (kW)
15
Degree of protection (IP)
IP20
Rated control supply voltage Us at AC 50HZ (V)
110…240 Volt
Rated control supply voltage Us at AC 60HZ (V)
110…240 Volt
Voltage type for actuating
AC/DC
Rated control supply voltage Us at DC (V)
110…220 Volt
Suitable for emergency stop
No
Type of electrical connection of main circuit
Screw connection
Number of indicator lights
0
Supporting protocol for SERCOS
No
Rated conditional short-circuit current, type 1, 480 Y/277 V (A)
10000
Rated conditional short-circuit current, type 2, 230 V (A)
50000
Rated operation current Ie (A)
32
Rated conditional short-circuit current, type 1, 600 Y/347 V (A)
4000
External reset possible
No
Ambient temperature, upper operating limit (°C)
70
With transformer
No
Rated operation current at AC-3, 400 V (A)
32
Type of electrical connection for auxiliary- and control current circuit
Screw connection
Rated conditional short-circuit current, type 2, 400 V (A)
50000
Height (mm)
224
Supporting protocol for INTERBUS-Safety
No
Number of command positions
3
Width (mm)
45
Number of auxiliary contacts as normally closed contact
1
Supporting protocol for AS-Interface Safety at Work
No
Number of auxiliary contacts as normally open contact
1
Coordination class according to IEC 60947-4-3
Class 2
Depth (mm)
126
Supporting protocol for DeviceNet Safety
No
Supporting protocol for EtherNet/IP
No
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for SafetyBUS p
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for PROFINET IO
No
Supporting protocol for PROFIsafe
No
Supporting protocol for ASI
No
Rated operation power at AC-3, 230 V, 3-phase (kW)
7.5
Kind of motor starter
Reversing starter
Supporting protocol for PROFIBUS
No
Supporting protocol for TCP/IP
No
Supporting protocol for CAN
No
Supporting protocol for INTERBUS
No
Rail mounting possible
Yes
Supporting protocol for DeviceNet
No
Supporting protocol for MODBUS
No
Supporting protocol for Data-Highway
No
Supporting protocol for LON
No
With fuse
No
Supporting protocol for other bus systems
No
With short-circuit release
Yes
Supporting protocol for SUCONET
No
Rated power, 575 V, 60 Hz, 3-phase (kW)
15
Rated power, 460 V, 60 Hz, 3-phase (kW)
15
