Max. nazivni tok (A)
12
Voltage type for actuating
DC
Rated control supply voltage Us at DC (V)
24 V
Voltage type of supply voltage
DC
Number of poles
3
Height (mm)
66
Width (mm)
45
Depth (mm)
60
Type of motor protection
Electronic release
Initial value of the undelayed short-circuit release - setting range (A)
156
End value adjustment range undelayed short-circuit release (A)
156
With ground fault protection function
Yes
Overload release current setting (A)
3…12 Ampere
Short-circuit release function
Undelayed
Operating voltage at AC 50 Hz (V)
690 Volt
Operating voltage at AC 60 Hz (V)
690 Volt
Voltage type (operating voltage)
AC
External power supply required
Yes
