Tip
iEM2000
Montaža
DIN letev
Komunikacija
Modbus
Vrsta produkta
merilnik
Merjenje (A)
100 A
Zahtevnost merjenja
napredno
Frequency (Hz)
45…65 Hertz
Width in number of modular spacings
2
Degree of protection (IP)
IP20
Model
Direct measurement
Mounting method
DRA (DIN-rail adapter)
Height (mm)
96.71
Width (mm)
35.8
Depth (mm)
63
Degree of protection (NEMA)
4X
Suitable for
Purchase
Type of interface
Modbus
Max. current (Imax) (A)
100
Calibrated
Yes
Approval
Measuring Instruments Directive
Pulse output
Electrical
Escapement mechanism
No
Energy type
Effective power and blind power
Accuracy class
B
Number of positions total (counter)
7
Tariff type
Two-tariff
Type of indication
Digital
Pole type
Single phase
Measuring type load profile
No
EEC40 signature
No
With lock code
No
Nominal current (In) (A)
100
Type of meter
Electronic
Nominal voltage (Un) N-L (V)
195…253 Volt
Pulse type
S0
Pulse rate (Imp/kWh (kvarh))
0.01…10000 Pulse constant
Tariff control
External
