Tok
32
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
1 NO
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
0 NC
Krmilna napetost (V AC)
240 V AC
Krmilna napetost (V DC)
110 V DC
Built-in depth (mm)
84
Width in number of modular spacings
1
Rated current (A)
32
Number of contacts as normally open contact
1
Number of contacts as change-over contact
0
Number of contacts as normally closed contact
0
Mounting method
DIN rail
Frequency control voltage 1 (Hz)
50…60 Hertz
Voltage type of supply voltage
AC
Supply voltage (V)
24…250 Volt
Control voltage 1 (V)
230…240 Volt
Type of control voltage 1
AC
Max. switching current (cos phi = 0.6) (A)
32
Function
Mechanical
Type of control voltage 2
DC
Control voltage 2 (V)
110 Volt
Max. load fluorescent lamp (parallel compensated) (VA)
2400
Max. incandescent lamp load (W)
4200
Max. load fluorescent lamp (VA)
3350
Max. load fluorescent lamp (Duo circuit) (VA)
5300
