Tok
16
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
1 NO
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
0 NC
Krmilna napetost (V AC)
48 V AC
Krmilna napetost (V DC)
24 V DC
Built-in depth (mm)
43.5
Width in number of modular spacings
1
Number of contacts as normally open contact
1
Number of contacts as change-over contact
0
Number of contacts as normally closed contact
0
Mounting method
DIN rail
Frequency control voltage 1 (Hz)
50…60 Hertz
Voltage type of supply voltage
AC
Supply voltage (V)
24…250 Volt
Control voltage 1 (V)
48 Volt
Type of control voltage 1
AC
Max. switching current (cos phi = 0.6) (A)
16
Function
Mechanical switch
Type of control voltage 2
DC
Control voltage 2 (V)
24 Volt
Rated switch current (A)
16
Manual operation possible
Yes
Max. load fluorescent lamp (parallel compensated) (VA)
900
Max. incandescent lamp load (W)
1600
Max. load fluorescent lamp (VA)
1300
Max. load fluorescent lamp (Duo circuit) (VA)
2000
Suitable for manual operation
Yes
