Tip
XB4
Tip napetosti
AC/DC
Material
kromirana kovina
Premer (mm)
22 mm
Napetost (V)
24 V
Vrsta produkta
stikalo
Oznaka na glavi
ne
Barva glave
zelena
ATEX
ne
Št. kontaktov NO
1 NO
Št. kontaktov NC
1 NC
Svetleča z LED
da
Tip upravljanja
zasuk
Degree of protection (IP)
IP66
Number of contacts as normally open contact
1
Number of contacts as change-over contact
0
Number of contacts as normally closed contact
1
Type of electric connection
Screw connection
Supply voltage (V)
24 Volt
Degree of protection (NEMA)
13
Spring-return
No
Switching function latching
Yes
Colour button
Green
With front ring
Yes
Suitable for illumination
Yes
With light source
Yes
Hole diameter (mm)
22.5
Type of control element
Short thumb-grip
Colour front ring
Chrome
Number of switch positions
2
Material front ring
Metal
