Max. nazivni tok (A)
80
Št. polov
3 P
Tip napetosti
DC
Vrsta produkta
zaščitna enota
Za odklopnik tipa
NSX100
Tip zaščite
TMD
Tok zaščite (A)
80 A
Voltage type for actuating
DC
Rated switch current (A)
80
Number of poles
3
Height (mm)
60.6
Width (mm)
104.7
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Depth (mm)
88.2
Type of motor protection
Thermal/magnetic release
Initial value of the undelayed short-circuit release - setting range (A)
800
End value adjustment range undelayed short-circuit release (A)
640
With ground fault protection function
No
Overload release current setting (A)
56…80 Ampere
Short-circuit release function
Undelayed
Number of auxiliary contacts as change-over contact
0
Operating voltage at DC (V)
750 Volt
Voltage type (operating voltage)
DC
External power supply required
No
Current setting undelayed short-circuit release (Ampere)
800 Ampere
