Tok
32
Št. polov
2 P+E
Tip napetosti
AC
IP zaščita
IP44
Montaža
kotna
Vrsta produkta
vtičnica
Max. napetost (V)
250 V
Degree of protection (IP)
IP44
Number of poles
3
Material
Plastic
RAL-number
7035
Rated voltage (V)
200…250 Volt
IEC-amperage (A)
32
Connection system
Screwed terminal
Voltage acc. EN 60309-2
230 V (50+60 Hz) blue
Identification colour
Blue
Clock hour position (h)
6
Military model
No
Flange size vertical (mm)
100
Flange size horizontal (mm)
90
Angle of plug
Angled
Rated frequency (Hz)
50…60 Hertz
Drill hole distance horizontal (mm)
77
Drill hole distance vertical (mm)
85
