Tok
32
Št. polov
3 P+N+E
Tip napetosti
AC
IP zaščita
IP44
Montaža
kotna
Vrsta produkta
vtičnica
Max. napetost (V)
250 V
Degree of protection (IP)
IP44
Number of poles
5
Material
Plastic
RAL-number
7035
Rated voltage (V)
200…250 Volt
Cable entry
None
IEC-amperage (A)
32
Connection system
Screw less terminal
Voltage acc. EN 60309-2
230 V (50+60 Hz) blue
Identification colour
Blue
Clock hour position (h)
9
Military model
No
Flange size vertical (mm)
100
Flange size horizontal (mm)
90
Angle of plug
Angled
Rated frequency (Hz)
50…60 Hertz
Drill hole distance horizontal (mm)
77
