Max. nazivni tok (A)
150
Max. nazivna moč pri 400 V AC (kW)
7.5
Frekvenca (Hz)
50/60 Hz
Vrsta priklopa
vijačni
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
1
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
1
Tip napetosti
AC/DC
Krmilna napetost (V)
48-130 V
Tip bremena
AC-3
Vrsta kontaktorja
visoko zmogljivostni
Rated control supply voltage Us at AC 50HZ (V)
48…130 Volt
Rated control supply voltage Us at AC 60HZ (V)
48…130 Volt
Voltage type for actuating
AC/DC
Rated control supply voltage Us at DC (V)
48…130 Volt
Type of electrical connection of main circuit
Bolt connection
Height (mm)
193
Width (mm)
108
Number of auxiliary contacts as normally closed contact
1
Number of auxiliary contacts as normally open contact
1
Depth (mm)
193
Rated operation power NEMA (kW)
100
Rated operation current Ie at AC-3, 400 V (A)
150
Number of normally closed contacts as main contact
0
Number of main contacts as normally open contact
3
Modular version
No
Rated operation current Ie at AC-1, 400 V (A)
275
Rated operation current Ie at AC-4, 400 V (A)
150
Rated operation power at AC-4, 400 V (kW)
7.5
Operating voltage at AC 50 Hz (V)
1000 Volt
Operating voltage at AC 60 Hz (V)
1000 Volt
