Tip napetosti
AC
Napetost (V)
115 V
Vrsta produkta
ventilator
Termostat
NSYCCOTHO
Pretok zraka (m3/h)
65 m3/h
Velikost izreza (mm)
Ø 108 mm
Degree of protection (IP)
IP20
Voltage type
AC
Mounting method
Screw mounting
Colour
Black
Height (mm)
124
Width (mm)
124
Depth (mm)
55
Degree of protection (NEMA)
1
RAL-number
9005
Wall build in
No
EMC-version
No
Suitable for 19 inch rack mounting
No
Noise emission (dB(A))
50
Air circulator
Yes
With protective cover
Yes
Operating voltage at AC 50 Hz (V)
115 Volt
Operating voltage at AC 60 Hz (V)
115 Volt
Built as slide-in ventilator
Yes
Roof ventilator
No
With filter
Yes
Number of fans
1
Rated power (W)
22
Volume flow, freeblowing (m3/h)
65
