Tip napetosti
AC
Napetost (V)
230 V
Vrsta produkta
ventilator
Termostat
NSYCCOTHO
Pretok zraka (m3/h)
575 m3/h
Velikost izreza (mm)
291x291 mm
Degree of protection (IP)
IP54
Voltage type
AC
Mounting method
Screw mounting
Colour
Grey
Height (mm)
96
Width (mm)
340
Depth (mm)
340
Degree of protection (NEMA)
13
RAL-number
7035
Wall build in
No
EMC-version
No
Suitable for 19 inch rack mounting
No
Noise emission (dB(A))
64
Air circulator
Yes
With protective cover
No
Operating voltage at AC 50 Hz (V)
230 Volt
Operating voltage at AC 60 Hz (V)
230 Volt
Built as slide-in ventilator
Yes
Roof ventilator
Yes
With filter
No
Number of fans
1
Rated power (W)
85
Volume flow, freeblowing (m3/h)
575
