Vrsta produkta
varnostni modul
Type of electric connection
Screw connection
Model
Other
Voltage type for actuating
DC
Rated control supply voltage Us at DC (V)
24 V
Voltage type of supply voltage
DC
Control voltage 1 (V)
24 Volt
Type of control voltage 1
DC
Type of control voltage 2
DC
Control voltage 2 (V)
24 Volt
Rated switch current (A)
1.1
Height (mm)
94
Width (mm)
43.7
Depth (mm)
73
Rail mounting possible
Yes
SIL according to IEC 61508
3
Performance level acc. EN ISO 13849-1
Level e
Supply voltage DC (V)
24 Volt
With detachable clamps
No
Category according to EN 954-1
None
Power consumption (W)
11
With feedback circuit
No
Number of outputs, safety related, undelayed, with contact
3
With approval according to UL
Yes
Evaluation inputs
Other
Stop category acc. IEC 60204
1
With approval for TÜV
Yes
With approval for BG BIA
No
Suitable for monitoring of position switches
No
Suitable for monitoring of tactile sensors
No
Suitable for monitoring of valves
No
Type of safety acc. IEC 61496-1
None
Suitable for monitoring of magnetic switches
No
Suitable for monitoring of proximity switches
No
Suitable for monitoring of emergency-stop circuits
Yes
Suitable for monitoring of optoelectronic protection equipment
No
With muting function
No
With start input
No
Operating voltage at DC (V)
24 Volt
Release-delay (s)
0.04 Second
Voltage type (operating voltage)
DC
With approval for TÜV
Yes
