Tip
XPSU
Tip napetosti
AC/DC
Napetost (V)
24 V
Fukcija modula
izklop v sili, varnostna ograja, varnostno stikalo, varnostna zavesa, varnostni tepih
Snemljive priključne sponke
da
Časovni zamik
da
Vhodi
3
Izhodi
3 NO + 1 NC
Type of electric connection
Spring clamp connection
Model
Basic device
Rated control supply voltage Us at AC 50HZ (V)
24 V
Rated control supply voltage Us at AC 60HZ (V)
24 V
Voltage type for actuating
AC/DC
Rated control supply voltage Us at DC (V)
24 V
Voltage type of supply voltage
AC/DC
Control voltage 1 (V)
24 Volt
Type of control voltage 1
AC/DC
Type of control voltage 2
AC/DC
Rated switch current (A)
0.02
Height (mm)
100
Width (mm)
45
Depth (mm)
120
Rail mounting possible
Yes
SIL according to IEC 61508
3
Performance level acc. EN ISO 13849-1
Level e
Supply voltage DC (V)
24 Volt
Operating voltage at AC 50 Hz (V)
24 Volt
Operating voltage at AC 60 Hz (V)
24 Volt
With detachable clamps
Yes
Category according to EN 954-1
4
Supply voltage AC 50 Hz (V)
24 Volt
Supply voltage AC 60 Hz (V)
24 Volt
Power consumption (W)
3
Number of outputs, safety related, delayed, with contact
4
Number of outputs, safety related, undelayed, semiconductors
0
With feedback circuit
Yes
Number of outputs, safety related, undelayed, with contact
3
With approval according to UL
Yes
Number of outputs, signalling function, delayed, with contact
0
Number of outputs, safety related, delayed, semiconductors
0
Number of outputs, signalling function, undelayed, with contact
0
Evaluation inputs
2-channel
Stop category acc. IEC 60204
0 + 1
With approval for TÜV
Yes
With approval for BG BIA
No
Number of outputs, signalling function, undelayed, semiconductors
0
Number of outputs, signalling function, delayed, semiconductors
0
Suitable for monitoring of position switches
Yes
Suitable for monitoring of tactile sensors
No
Suitable for monitoring of valves
No
Type of safety acc. IEC 61496-1
4
Suitable for monitoring of magnetic switches
Yes
Suitable for monitoring of proximity switches
Yes
Suitable for monitoring of emergency-stop circuits
Yes
Suitable for monitoring of optoelectronic protection equipment
Yes
With muting function
No
With start input
Yes
Operating voltage at DC (V)
24 Volt
Release-delay (s)
0…900 Second
Voltage type (operating voltage)
AC/DC
With approval for TÜV
Yes
