Tip
XB5
Tip napetosti
AC
Premer (mm)
22 mm
Napetost (V)
120 V
Vrsta produkta
urni števec
Oznaka na glavi
ne
Možnost osvetlitve
ne
Built-in depth (mm)
60
Width in number of modular spacings
30
Degree of protection (IP)
IP65
Voltage type
AC
Model
Front mounting
Mounting method
Surface and panel mounting
Height (mm)
30
Width (mm)
30
Degree of protection (NEMA)
4X
Modular version
No
Mounting to max. wall thickness (mm)
0
Input voltage (V)
120 Volt
Number of digits
5
Frequency input voltage (Hz)
50…60 Hertz
Type of drive
Quartz
Front plate width (mm)
30
Reset function
None
Front plate height (mm)
30
Diameter panel opening (mm)
22
Operation indication
No
Count area (h)
0
Accuracy per day (s)
60
Input voltage at AC 50 Hz (V)
108…132 Volt
Input voltage at AC 60 Hz (V)
108…132 Volt
Number of semiconductor outputs with signalling function
0
Number of contact energized outputs with signalling function
0
Measuring mechanism
Other
With reset function
No
Frequency input voltage (Hertz)
60
