Tip
XB5
Tip napetosti
AC/DC
Premer (mm)
22 mm
Napetost (V)
24 V
Vrsta produkta
urni števec
Oznaka na glavi
ne
Možnost osvetlitve
ne
Built-in depth (mm)
60
Degree of protection (IP)
IP65
Voltage type
AC/DC
Model
Front mounting
Mounting method
Surface and panel mounting
Height (mm)
30
Width (mm)
30
Degree of protection (NEMA)
13
Modular version
No
Mounting to max. wall thickness (mm)
6
Input voltage (V)
12…24 Volt
Number of digits
5
Frequency input voltage (Hz)
50…60 Hertz
Type of drive
Mains synchronous
Front plate width (mm)
30
Reset function
None
Front plate height (mm)
30
Diameter panel opening (mm)
22.5
Operation indication
Yes
Count area (h)
9999
Input voltage at DC (V)
12…24 Volt
Input voltage at AC 50 Hz (V)
12…24 Volt
Input voltage at AC 60 Hz (V)
12…24 Volt
Number of semiconductor outputs with signalling function
0
Number of contact energized outputs with signalling function
0
Measuring mechanism
Other
With reset function
No
Frequency input voltage (Hertz)
60
