Tip
SBM
Višina omare (mm)
200
Širina omare (mm)
600
Globina omare (mm)
80
Material
INOX
Tip vrat
navadna
Število vrat
1
Tip namestitve
zidna
IP zaščita
IP66
RAL
RAL 7035
Degree of protection (IP)
IP66
Mounting method
Surface mounted
Sealable
No
Colour
Grey
Length (mm)
200
Width (mm)
600
Depth (mm)
80
Degree of protection (NEMA)
4X
Halogen free
Yes
With transparent cover
No
Shape
Rectangular
Material
Steel
RAL-number
7035
Impact strength
IK10
Surface protection
Other
Extension possible
No
Plate thickness cabinet (mm)
1.2
Circuit integrity
None
For Ex-zone gas
None
With cover
Yes
Working temperature (°C)
-35…80 Degrees celsius
Number of inlets
0
Number of connection clamps
0
Cover attachment
Screwed
For Ex-Zone dust
None
Explosion-tested version
No
Connection type
Screwed terminal
Compliant with BS 6220
No
Maintenance free in accordance with BS 5733
Yes
