Namen
motor
Max. nazivni tok (A)
115, 115
Max. nazivna moč pri 400 V AC (kW)
5.5, 5.5
Frekvenca (Hz)
50/60 Hz
Vrsta priklopa
vijačni
Možnost indikacije kratkega stika
da
Vrsta MZS
termo magnetno motorsko zaščitno stikalo
Kratkostični tok (kA)
25, 25
Degree of protection (IP)
IP40
Number of poles
3
Type of electrical connection of main circuit
Screw connection
Height (mm)
155
Width (mm)
81
Depth (mm)
116
Overload release current setting (A)
65…115 Ampere
Type of control element
Rocker lever
With integrated auxiliary switch
No
Switch off technique
Electronic
Rated operating voltage (V)
690 Volt
Rated operation power at AC-3, 230 V (kW)
30
Phase failure sensitive
Yes
With integrated under voltage release
No
Adjustment range undelayed short-circuit release (A)
1955 Ampere
With thermal protection
Yes
Device construction
Complete device in housing
Power loss (Watt)
13.8
