Max. nazivna moč pri 400 V AC (kW)
15
Degree of protection (IP)
IP20
Rated control supply voltage Us at AC 50HZ (V)
24 Volt
Rated control supply voltage Us at AC 60HZ (V)
24 Volt
Voltage type for actuating
AC
Function
Reversing contactor
Type of electrical connection of main circuit
Screw connection
Type of electrical connection for auxiliary- and control current circuit
Screw connection
Height (mm)
83.8
Width (mm)
448
Depth (mm)
112
Rail mounting possible
Yes
Rated operation power NEMA (kW)
14.9
Rated operation current Ie at AC-3, 400 V (A)
32
Degree of protection (NEMA)
Other
Operating voltage at AC 50 Hz (V)
690 Volt
Operating voltage at AC 60 Hz (V)
690 Volt
Voltage type (operating voltage)
AC
