Tip
XB4
Tip napetosti
AC
Material
kromirana kovina
Premer (mm)
22 mm
Napetost (V)
240 V
Vrsta produkta
tipka
Oznaka na glavi
ne
Barva glave
rdeča
ATEX
ne
Št. kontaktov NO
1 NO
Št. kontaktov NC
1 NC
Svetleča z LED
da
Tip upravljanja
povratna vzmet
Degree of protection (IP)
IP66
Number of contacts as normally open contact
1
Number of contacts as change-over contact
0
Number of contacts as normally closed contact
1
Type of electric connection
Screw connection
Number of command positions
1
Degree of protection (NEMA)
Other
Spring-return
Yes
Switching function latching
No
Type of button
Flat
Construction type lens
Round
Colour button
Red/green
With front ring
Yes
Suitable for illumination
Yes
Hole diameter (mm)
22.5
Transparent
Yes
Colour front ring
Chrome
Material front ring
Metal
Supply voltage lamp (V)
240
