Št. digitalnih izhodov
16
Vrsta produkta
razširitveni modul
Degree of protection (IP)
IP20
Type of electric connection
Screw connection
Voltage type of supply voltage
DC
Supporting protocol for SERCOS
No
Height (mm)
139
Supporting protocol for INTERBUS-Safety
No
Width (mm)
128.3
Supporting protocol for AS-Interface Safety at Work
No
Depth (mm)
70
Supporting protocol for DeviceNet Safety
No
Supporting protocol for EtherNet/IP
Yes
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for SafetyBUS p
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for PROFINET IO
No
Supporting protocol for PROFIsafe
No
Supporting protocol for ASI
No
Supporting protocol for PROFIBUS
Yes
Supporting protocol for TCP/IP
Yes
Supporting protocol for CAN
Yes
Supporting protocol for INTERBUS
Yes
Rail mounting possible
No
Supporting protocol for DeviceNet
Yes
Supporting protocol for MODBUS
Yes
Supporting protocol for Data-Highway
No
Supporting protocol for LON
No
Supporting protocol for other bus systems
No
Supporting protocol for SUCONET
No
SIL according to IEC 61508
None
System accessory
Yes
Performance level acc. EN ISO 13849-1
None
Radio standard GPRS
No
Fieldbus connection over separate bus coupler possible
Yes
Explosion safety category for dust
None
Radio standard GSM
No
Radio standard UMTS
No
Explosion safety category for gas
None
Radio standard Bluetooth
No
Radio standard WLAN 802.11
No
Appendant operation agent (Ex ia)
No
Front build in possible
No
Supporting protocol for KNX
No
Appendant operation agent (Ex ib)
No
IO link master
No
Suitable for safety functions
No
Supply voltage DC (V)
24 Volt
Rack-assembly possible
Yes
Wall mounting/direct mounting
No
Number of interfaces PROFINET
0
Number of HW-interfaces parallel
0
Number of HW-interfaces other
0
Number of HW-interfaces serial TTY
0
Number of HW-interfaces USB
0
With optical interface
No
Number of digital outputs
6
Number of digital inputs
0
Number of HW-interfaces RS-422
0
Number of HW-interfaces RS-485
0
Number of HW-interfaces industrial Ethernet
0
Number of HW-interfaces RS-232
0
Number of HW-interfaces Wireless
0
Category according to EN 954-1
1
Output current (A)
0.5
Short-circuit protection, outputs available
Yes
Digital inputs configurable
No
Type of digital output
Other
Digital outputs configurable
Yes
Type of voltage (input voltage)
DC
Type of output voltage
DC
Input current at signal 1 (mA)
0.4
Permitted voltage at output (V)
24 Volt
Permitted voltage at input (V)
19.2…30 Volt
Time delay at signal exchange (ms)
0.715…0.955 Millisecond
Supporting protocol for EtherCAT
No
Certified for UL hazardous location division 2
No
Certified for UL hazardous location class I
No
Certified for UL hazardous location class III
No
Certified for UL hazardous location division 1
No
Certified for UL hazardous location class II
No
Certified for UL hazardous location group C (ethylene)
No
Certified for UL hazardous location group A (acetylene)
No
Certified for UL hazardous location group B (hydrogen)
No
Certified for UL hazardous location group F (carbonaceous dusts)
No
Certified for UL hazardous location group G (non-conductive dusts)
No
Certified for UL hazardous location group D (propane)
No
Certified for UL hazardous location group E (metal dusts)
No
