Tip
PLAZT
Namen
univerzalna omara
Višina omare (mm)
1500
Širina omare (mm)
500
Globina omare (mm)
420
Material
poliester
Tip vrat
navadna
Število vrat
1
Tip namestitve
kompaktna prostostoječa omara
IP zaščita
IP44
RAL
RAL 7035
Montažna plošča
ne
Degree of protection (IP)
IP44
Colour
Grey
Height (mm)
1500
Width (mm)
500
Depth (mm)
420
Degree of protection (NEMA)
3
Material
Plastic
With mounting plate
No
With glazed door
No
Wall fastening possible
No
Suitable for metrical mounting
No
RAL-number
7035
Tackable
No
Pitched roof
No
Surface finishing
Untreated
Number of doors
1
Suitable for outdoor set-up
Yes
Number of locks
1
Material quality
Polyester (PET)
Wall build in
No
Mounting plate depth-adjustable
No
Impact strength
IK10
With ventilation door
No
EMC-version
No
Pole fastening
No
With backside door
No
Floor installation possible
Yes
Number of connector holes
0
Pre-stamping
No
Transparent cover
No
With cover
No
Couplable
No
Freestanding
No
Floor standing wall model
No
Intermediate mounting
No
Corner model
No
Suitable for wall mounting
Yes
Max. permissible load of the mounting plate according to IEC 62208 (Newton)
686
With door
Yes
Max. permissible load of the enclosure according to IEC 62208 (Newton)
902
Max. permissible load of the door(s) according to IEC 62208 (Newton)
216
