Tip
PHD
Namen
heavy duty omara
Višina omare (mm)
1343
Širina omare (mm)
750
Globina omare (mm)
620
Material
poliester
Tip vrat
navadna
Število vrat
1
Tip namestitve
kompaktna prostostoječa omara
IP zaščita
IP55
RAL
RAL 7035
Montažna plošča
ne
Degree of protection (IP)
IP55
Colour
Grey
Height (mm)
1343
Width (mm)
750
Depth (mm)
620
Degree of protection (NEMA)
12
Material
Plastic
With mounting plate
No
With glazed door
No
Wall fastening possible
No
Suitable for metrical mounting
Yes
RAL-number
7035
Tackable
Yes
Pitched roof
Yes
Surface finishing
Untreated
Number of doors
1
Suitable for outdoor set-up
Yes
Number of locks
1
Material quality
Polyester (PET)
Wall build in
No
Mounting plate depth-adjustable
No
Impact strength
IK10
With ventilation door
No
EMC-version
No
Pole fastening
No
With backside door
No
Floor installation possible
Yes
Transparent cover
No
With cover
No
Couplable
No
Floor standing wall model
Yes
Intermediate mounting
Yes
Corner model
No
Suitable for wall mounting
No
With door
Yes
Max. permissible load of the enclosure according to IEC 62208 (Newton)
500
Max. permissible load of the door(s) according to IEC 62208 (Newton)
28
