Degree of protection (IP)
IP55
Mounting method
Wall mounting
Height (mm)
342
Width (mm)
244
Depth (mm)
107
Material housing
Plastic
Impact strength
IK10
With display
No
Input voltage (V)
400 Volt
Frequency
50/60 Hz
IFTTT support available
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Networkable via Wi-Fi
Yes
Contactor welding detection
No
Radio standard 5G
No
Nominal connection power (Kilowatt)
11
Number of CEE socket outlets
0
Network-enabled as a master
No
DC residual current detection
Yes
Static load management integrated
No
With MID compliant energy meter
No
Number of earth leakage circuit breakers type A
0
Number of earth leakage circuit breakers type B
0
Suitable for dynamic load management
Yes
With built-in RFID card reader
No
Number of vehicle connectors Type 1 CCS
0
Number of vehicle connectors Type 1
0
Number of vehicle connectors Type 2 CCS
0
Number of vehicle connectors Type 2
1
Max. power per charging point (Kilowatt)
11
OpenChargePointProtocoll (OCPP) version
1.6
With key switch
No
Installation side connection model
3-phase
Export of charging logs
Yes
Network-enabled as an extender
No
Plug and charge (ISO 15118)
No
Operation and configuration by app
Yes
NFC (Near Field Communication)
No
Number of socket outlets Type 3
0
Number of vehicle connectors GB AC
0
Number of socket outlets Type 2
0
Number of socket outlets GB
0
Number of vehicle connectors GB DC
0
With energy meter
No
With miniature circuit breaker (MCB)
No
Number of charging units
1
Number of household socket outlets
0
Number of vehicle connectors CHAdeMO
0
Charging cable permanently lockable at charging device
No
Networkable via LAN
Yes
With house connection box
Yes
Length of charging cable (Metre)
5
