Kratkostična zmogljivost
36 kA
Max. nazivni tok (A)
1.6
Št. polov
4 P
Tip napetosti
AC
Nazivni tok (A)
100
Tip zaščite
TMD
Serija
NSXm
Tok zaščite (A)
16 A
Degree of protection (IP)
IP40
Number of poles
4
Type of electrical connection of main circuit
Screw connection
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Overload release current setting (A)
11.2…16 Ampere
Number of auxiliary contacts as change-over contact
0
Type of control element
Toggle
Adjustment range undelayed short-circuit release (A)
500 Ampere
Device construction
Built-in device fixed built-in technique
Rated voltage (V)
220…690 Volt
Suitable for DIN rail (top hat rail) mounting
Yes
Motor drive integrated
No
Motor drive optional
No
Complete device with protection unit
Yes
With under voltage release
No
DIN rail (top hat rail) mounting optional
No
With switched-off indicator
Yes
Position of connection for main current circuit
Front side
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz (kA)
36
Integrated earth fault protection
No
Power loss (Watt)
9.2
