Kratkostična zmogljivost
75 kA
Max. nazivni tok (A)
320
Št. polov
3 P
Tip napetosti
AC
Nazivni tok (A)
400
Tip zaščite
Micrologic 2.3 M
Serija
NSX
Tok zaščite (A)
320 A
Degree of protection (IP)
IP40
Number of poles
3
Type of electrical connection of main circuit
Screw connection
Height (mm)
255
Width (mm)
140
Depth (mm)
110
Overload release current setting (A)
160…320 Ampere
Type of control element
Other
With integrated auxiliary switch
No
Switch off technique
Electronic
Rated operating voltage (V)
690 Volt
Phase failure sensitive
Yes
With integrated under voltage release
No
Adjustment range undelayed short-circuit release (A)
4800 Ampere
With thermal protection
Yes
Device construction
Built-in device fixed built-in technique
Power loss (Watt)
57.6
