Kratkostična zmogljivost
200 kA
Max. nazivni tok (A)
250
Št. polov
3 P
Tip napetosti
AC
Nazivni tok (A)
250
Tip zaščite
Micrologic 2.2
Serija
NSX
Tok zaščite (A)
250 A
Degree of protection (IP)
IP40
Number of poles
3
Type of electrical connection of main circuit
Screw connection
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Overload release current setting (A)
100…250 Ampere
Number of auxiliary contacts as change-over contact
0
Type of control element
Toggle
With integrated under voltage release
No
Adjustment range undelayed short-circuit release (A)
3000 Ampere
Device construction
Built-in device fixed built-in technique
Rated voltage (V)
690 Volt
Suitable for DIN rail (top hat rail) mounting
No
Motor drive integrated
No
Motor drive optional
Yes
Complete device with protection unit
Yes
With under voltage release
No
DIN rail (top hat rail) mounting optional
Yes
With switched-off indicator
Yes
Position of connection for main current circuit
Front side
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz (kA)
200
Integrated earth fault protection
No
Adjustment range short-term delayed short-circuit release (A)
150…2500 Ampere
Power loss (Watt)
52.8
