Kratkostična zmogljivost
25 kA
Max. nazivni tok (A)
125
Št. polov
1 P
Tip napetosti
DC
Nazivni tok (A)
160
Tip zaščite
TMD
Serija
NSX
Tok zaščite (A)
125 A
Degree of protection (IP)
IP40
Number of poles
1
Type of electrical connection of main circuit
Screw connection
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Overload release current setting (A)
125 Ampere
Number of auxiliary contacts as change-over contact
0
Type of control element
Toggle
With integrated under voltage release
No
Adjustment range undelayed short-circuit release (A)
1200 Ampere
Device construction
Built-in device fixed built-in technique
Rated voltage (V)
277 Volt
Suitable for DIN rail (top hat rail) mounting
No
Motor drive integrated
No
Motor drive optional
No
Complete device with protection unit
Yes
With under voltage release
No
DIN rail (top hat rail) mounting optional
Yes
With switched-off indicator
Yes
Position of connection for main current circuit
Front side
Integrated earth fault protection
No
Power loss (Watt)
10.78
