Tip
XPEM
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
2 NO
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
2 NC
Material
kovina
IP zaščita
IP66
Barva
modra
Stopalo
enojno
Upravljanje kontaktov
1 korak
Analogni izhod
da
Varnostni sprožilec (trigger)
ne
Pokrov
da
Degree of protection (IP)
IP66
Number of contacts as normally open contact
2
Number of contacts as change-over contact
0
Number of contacts as normally closed contact
2
Rated operation current Ie at AC-15, 230 V (A)
3
Colour
Blue
Height (mm)
135
Width (mm)
160
Depth (mm)
18.6
Degree of protection (NEMA)
Other
Suitable for safety functions
Yes
Switching function latching
No
Material
Metal
Number of switch positions
1
With protective insulation
No
With protection hood
Yes
Type of command
On or off
With interlocking
Yes
Number of switch levels
1
