Max. nazivni tok (A)
5
Rated control supply voltage Us at AC 50HZ (V)
24 V
Rated control supply voltage Us at AC 60HZ (V)
24 V
Voltage type for actuating
AC
Voltage type of supply voltage
AC
Number of poles
3
Height (mm)
66
Width (mm)
45
Depth (mm)
60
Type of motor protection
Electronic release
Initial value of the undelayed short-circuit release - setting range (A)
65
End value adjustment range undelayed short-circuit release (A)
65
With ground fault protection function
Yes
Overload release current setting (A)
1.25…5 Ampere
Short-circuit release function
Undelayed
Operating voltage at AC 50 Hz (V)
690 Volt
Operating voltage at AC 60 Hz (V)
690 Volt
Voltage type (operating voltage)
AC
External power supply required
Yes
