Maksimalno število stikal v kaskadi
Neomejeno
Serija izdelka
Modicon
Ethernet vhod
10/100BASE-TX - 6 Bakren kabel, 100BASE-FX - 2 Optična vlakna
Izdelek ali sestavni del
Ethernet neupravljalno stikalo TCP/IP
Protokol komunikacijskih vrat
Ethernet TCP/IP
Koncept
Transparent Ready
Degree of protection (IP)
IP30
Mounting method
DIN rail (top hat rail)
Height (mm)
110
Width (mm)
45
Depth (mm)
88
Number of ports 10/100 Mbps RJ45
6
Number of ports 10 Gbps RJ45
0
Number of ports 100 Gbps Mini GBIC
0
Number of ports 40 Gbps Mini GBIC
0
Manageable
No
Number of ports 1000 Mbps GBIC
0
Number of ports 10/100 Mbps M12
0
Number of ports 10/100/1000 Mbps RJ45
0
Number of ports 100 Mbps POF
0
Number of ports 1000 Mbps SC (SX)
0
Number of ports 1000 Mbps Mini GBIC
0
Number of combination-ports RJ45/Mini GBIC
0
Number of ports 100 Mbps SC
2
Number of ports 100 Mbps ST
0
Number of ports 1000 Mbps RJ45
0
Number of max. stackable switches
0
Max. PoE power (W)
0
Number of ports 100/1000 Mbps Mini GBIC
0
Number of ports 1000 Mbps SC (LX)
0
Layer 2
Yes
Number of module slots
0
Layer 3
No
Number of ports 1000 Mbps POF
0
Number of ports PoE
0
Ethernet
Yes
Power over Ethernet
Other
Number of ports 10 Gbps Mini GBIC
0
Number of other ports
0
Compatible with Grade2TV according to XP-C 90-483
No
Compatible with Grade3TV according to XP-C 90-483
No
Redundant power supply
No
Max. power consumption (Watt)
3.8
