Max. nazivna moč pri 400 V AC (kW)
335
Voltage type for actuating
DC
Rated control supply voltage Us at DC (V)
220 Volt
Type of electrical connection of main circuit
Bolt connection
Height (mm)
304
Width (mm)
309
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Depth (mm)
255
Rated operation current Ie at AC-3, 400 V (A)
630
Number of normally closed contacts as main contact
0
Number of main contacts as normally open contact
3
Modular version
No
Rated operation current Ie at AC-1, 400 V (A)
1000
Rated operation current Ie at AC-4, 400 V (A)
200
Rated operation power at AC-4, 400 V (kW)
100
Operating voltage at AC 50 Hz (V)
1000 Volt
Operating voltage at AC 60 Hz (V)
1000 Volt
