Max. nazivna moč pri 400 V AC (kW)
7.5
Rated control supply voltage Us at AC 50HZ (V)
220…230 Volt
Rated control supply voltage Us at AC 60HZ (V)
220…230 Volt
Voltage type for actuating
AC/DC
Rated control supply voltage Us at DC (V)
220…230 Volt
Type of electrical connection of main circuit
Bolt connection
Height (mm)
170
Width (mm)
163.5
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Depth (mm)
171
Rated operation current Ie at AC-3, 400 V (A)
150
Number of normally closed contacts as main contact
0
Number of main contacts as normally open contact
3
Modular version
No
Rated operation current Ie at AC-1, 400 V (A)
250
Rated operation current Ie at AC-4, 400 V (A)
50
Rated operation power at AC-4, 400 V (kW)
2.2
Operating voltage at AC 50 Hz (V)
1000 Volt
Operating voltage at AC 60 Hz (V)
1000 Volt
