Max. nazivni tok (A)
400
Št. polov
4 P
Tip napetosti
DC
Nazivni tok (A)
400
Tip zaščite
brez
Serija
NSX
Number of poles
4
Type of electrical connection of main circuit
Screw connection
Height (mm)
140
Width (mm)
161
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Depth (mm)
86
Number of auxiliary contacts as change-over contact
0
Type of control element
Toggle
Rated operating voltage (V)
1000 Volt
Device construction
Built-in device fixed built-in technique
Degree of protection (IP), front side
IP30
Suitable for distribution board installation
Yes
Suitable for intermediate mounting
No
Suitable for ground mounting
Yes
Colour control element
Black
Version as emergency stop installation
No
Version as reversing switch
No
Suitable for front mounting centre
No
Max. rated operation voltage Ue AC (V)
1000
Version as main switch
Yes
Rated short-time withstand current lcw (kA)
6
Voltage release optional
Yes
Interlockable
Yes
Version as maintenance-/service switch
Yes
Version as safety switch
No
Suitable for front mounting 4-hole
Yes
Motor drive integrated
No
Number of switches
1
Motor drive optional
Yes
Rated permanent current at AC-23, 400 V (A)
400
Rated permanent current at AC-21, 400 V (A)
400
With pre-assembled cabling
No
