Max. nazivna moč pri 400 V AC (kW)
11
Voltage type for actuating
DC
Rated control supply voltage Us at DC (V)
220 Volt
Type of electrical connection of main circuit
Spring clamp connection
Height (mm)
99
Width (mm)
45
Number of auxiliary contacts as normally closed contact
1
Number of auxiliary contacts as normally open contact
1
Depth (mm)
101
Rated operation current Ie at AC-3, 400 V (A)
25
Number of normally closed contacts as main contact
0
Number of main contacts as normally open contact
3
Modular version
No
Rated operation current Ie at AC-1, 400 V (A)
40
Rated operation current Ie at AC-4, 400 V (A)
12
Rated operation power at AC-4, 400 V (kW)
5.5
