Tip
XD2
Premer (mm)
30 mm
Vrsta produkta
kompletna krmilna palica
Št. smeri
8
Št. kontaktov NO/NC na smer
1 ali 2 C/O
Degree of protection (IP)
IP65/IP67
Degree of protection (NEMA)
Other
With front ring
Yes
With retraction in 0-position
No
Colour front ring
Chrome
Number of switch positions
8
Material front ring
Metal
Rated operation current Ie at AC-21, 400 V (A)
10
Number of normally open contacts per actuation direction
0
Analogue output signal configurable
No
Joy stick length (mm)
80
Coder
No
Number of make-and-break contacts per direction
0
Centre mounting, hole diameter (mm)
30
Number of actuation directions
8
Locking in 0-position
No
Number of normally closed contacts per actuation direction
0
Number of switch levels
0
