Tip
Kaedra
Vrsta produkta
kabelska tesnilka
Degree of protection (IP)
IP65
Model
Straight
Colour
Grey
Halogen free
Yes
Material
Plastic
RAL-number
7035
Material quality
Polyamide (PA)
EMC-version
No
Surface protection
Untreated
For Ex-zone gas
None
Working temperature (°C)
-25…40 Degrees celsius
For Ex-Zone dust
None
Explosion-tested version
No
Thread type
PG
Wrench width (mm)
24
Pitch thread (mm)
1.41
With strain relief
No
For armoured cable
No
With locknut
Yes
Multi seal area
No
Suitable for cable diameter (mm)
9…12 Millimetre
Type of sealing
Cut-out ring
Nominal thread size metric/PG
13.5
Glass-fibre reinforced
No
Separable screw gland
Yes
Flat cable coupling
No
Screened
No
Shock resistant
Yes
Nominal thread size inch/gas pipe thread
Other
Thread length (mm)
9
Snapping in opening
No
