Tok
63
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
4 NO
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
0 NC
Krmilna napetost (V AC)
24 V AC
Built-in depth (mm)
43.5
Width in number of modular spacings
3
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Number of contacts as normally open contact
4
Number of contacts as normally closed contact
0
Number of modular spacings
3
Rated operating voltage (V)
400 Volt
Max. load fluorescent lamp (parallel compensated) (VA)
10500
Max. incandescent lamp load (W)
22500
Max. load fluorescent lamp (VA)
11550
Rated excitation voltage (V)
24 Volt
Rated operation current (A)
63
Utility category
7
Slider for hand switch
Yes
Voltage type (operating voltage)
AC
Voltage type (excitation voltage)
AC
Max. load fluorescent lamp (Duo circuit) (VA)
17700
With day/night function
No
Hum-free
No
