Tok
63
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
2 NO
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
0 NC
Krmilna napetost (V AC)
24 V AC
Built-in depth (mm)
43.5
Width in number of modular spacings
2
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Number of contacts as normally open contact
2
Number of contacts as normally closed contact
0
Number of modular spacings
2
Rated operating voltage (V)
250 Volt
Max. load fluorescent lamp (parallel compensated) (VA)
3500
Max. incandescent lamp load (W)
7500
Max. load fluorescent lamp (VA)
3850
Rated excitation voltage (V)
24 Volt
Rated operation current (A)
63
Utility category
7
Slider for hand switch
Yes
Voltage type (operating voltage)
AC
Voltage type (excitation voltage)
AC
Max. load fluorescent lamp (Duo circuit) (VA)
5900
Utilization category according to EN IEC 60947-4-1
AC-7a/AC-7b
