Tok
16
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
1 NO
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
0 NC
Krmilna napetost (V AC)
48 V AC
Built-in depth (mm)
43.5
Width in number of modular spacings
1
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Number of contacts as normally open contact
1
Number of contacts as normally closed contact
0
Number of modular spacings
1
Rated operating voltage (V)
250 Volt
Max. load fluorescent lamp (parallel compensated) (VA)
800
Max. incandescent lamp load (W)
2000
Max. load fluorescent lamp (VA)
850
Rated excitation voltage (V)
48 Volt
Rated operation current (A)
16
Utility category
7
Slider for hand switch
No
Voltage type (operating voltage)
AC
Voltage type (excitation voltage)
AC
Max. load fluorescent lamp (Duo circuit) (VA)
1500
Utilization category according to EN IEC 60947-4-1
AC-7a/AC-7b
