Tok
100
Število pomožnih kontaktov kot normalno odprtih kontaktov (NO)
2 NO
Število pomožnih kontaktov kot normalno zaprtih kontaktov (NC)
0 NC
Krmilna napetost (V AC)
240 V AC
Built-in depth (mm)
43.5
Width in number of modular spacings
3
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Number of contacts as normally open contact
2
Number of contacts as normally closed contact
0
Number of modular spacings
3
Rated operating voltage (V)
250 Volt
Max. load fluorescent lamp (parallel compensated) (VA)
0
Max. incandescent lamp load (W)
0
Max. load fluorescent lamp (VA)
0
Rated excitation voltage (V)
220…240 Volt
Rated operation current (A)
100
Utility category
7
Slider for hand switch
No
Voltage type (operating voltage)
AC
Voltage type (excitation voltage)
AC
Max. load fluorescent lamp (Duo circuit) (VA)
0
With day/night function
No
Hum-free
No
Utilization category according to EN IEC 60947-4-1
AC-1
