Tok
63
Št. polov
3 P+E
Tip napetosti
AC
IP zaščita
IP67
Montaža
kotna
Vrsta produkta
vtičnica
Max. napetost (V)
500 V
Degree of protection (IP)
IP67
Number of poles
4
Material
Plastic
RAL-number
7035
Rated voltage (V)
480…500 Volt
IEC-amperage (A)
63
Connection system
Screwed terminal
Voltage acc. EN 60309-2
500 V (50+60 Hz) black
Identification colour
Black
Clock hour position (h)
7
Military model
No
Flange size vertical (mm)
107
Flange size horizontal (mm)
100
Angle of plug
Angled
Rated frequency (Hz)
50…60 Hertz
Drill hole distance horizontal (mm)
77
