Tok
32
Št. polov
3 P
Tip napetosti
AC
IP zaščita
IP44
Montaža
ravna
Vrsta produkta
vtičnica
Max. napetost (V)
50 V
Degree of protection (IP)
IP44
Number of poles
3
Material
Plastic
RAL-number
7035
Rated voltage (V)
40…50 Volt
Cable entry
None
IEC-amperage (A)
32
Connection system
Screwed terminal
Voltage acc. EN 60309-2
40-50 V (50+60 Hz) white
Identification colour
White
Military model
No
Flange size vertical (mm)
65
Flange size horizontal (mm)
65
Angle of plug
Straight
Rated frequency (Hz)
50…60 Hertz
Drill hole distance horizontal (mm)
77
