Tok
16
Št. polov
3 P
Tip napetosti
AC
IP zaščita
IP44
Montaža
ravna
Vrsta produkta
vtičnica
Max. napetost (V)
25 V
Degree of protection (IP)
IP44
Number of poles
3
Material
Plastic
RAL-number
7035
Rated voltage (V)
20…25 Volt
Cable entry
None
IEC-amperage (A)
16
Connection system
Screwed terminal
Voltage acc. EN 60309-2
20-25 V / 40-50 V (100-200 Hz) green
Identification colour
Green
Military model
No
Flange size vertical (mm)
65
Flange size horizontal (mm)
65
Angle of plug
Straight
Rated frequency (Hz)
401…500 Hertz
Drill hole distance horizontal (mm)
52
